How to Install the Outdoor Wall Panel

Preparations before installation

Measuring Your Space

The first step is to accurately measure the area where you will be installing the panels. Measure the height and width of the wall, and be sure to consider windows, doors, or other obstructions. It's best to draw a simple sketch of the wall and record all dimensions.

Estimating Your Material Quantity

After selecting the panels, you will need to calculate the number of panels required to complete the project. Our panels feature an interlocking design, making it easy to calculate the coverage area. Don't forget to order necessary accessories such as corner protectors and screws.

Required Tools and Materials

Having the right tools and materials will make the installation process much easier. Here is a list of items you will need:

● Measuring tape

● Grade

● Pencil

● Chalk line

● Circular saw or miter saw

● Screwdriver drill bit

● Wall detector

● Safety glasses

● Gloves

● Outdoor grade screws

Clean the Wall Surface

First, thoroughly clean the wall surface. Use a pressure washer or a stiff-bristled brush with soapy water to remove dirt, dust, or debris. Allow the wall to dry completely before proceeding to the next step.

Inspect and Repair

Inspect the wall for damage such as cracks, holes, or rot. Repair any damage before installation. A stable wall is essential for successful installation.

Mark the Layout

Mark the panel layout on the wall with chalk lines. This will help you keep the panels straight and level during installation. Use a wall detector to locate the wall posts and mark them with a pencil.

Installation steps

Step 1: Measure and Plan the Layout

Measure the height and width of the area where you will be installing the panels. This will help you determine the number of panels you need to purchase. Plan the layout, determining the starting point and how to handle corners and edges. It's generally best to start from the bottom corner and then lay them horizontally upwards.

Step 2: Create the Starting Line

Use a level and chalk line to draw a straight, horizontal starting line at the bottom of the installation area. This line will guide you in placing the first row of panels, so make sure it's level. An uneven first row will affect the overall installation.

Step 3: Install Leveling Strips

Establishing the joist system is a necessary step to ensure a strong and durable installation. This framing structure creates a completely flat and stable surface for installing the panels and provides necessary airflow gaps, which is crucial for effective humidity control.

Step 4: Cut the Panels to the Desired Size

You may need to cut some panels for installation around windows, doors, and at the ends of walls. Measure carefully and make clean, precise cuts using a circular saw or miter saw. Always wear safety glasses when cutting material.

Step 5: Install the First Panel

Firmly attach the first panel against the horizontal wooden strips on either side of the starting line. Secure the panel by nailing it directly into the strips using outdoor-grade screws through the designated tongue and groove of the interlocking system. This method hides the screws, resulting in a clean, professional look. Before proceeding to the next step, check that the panel is level.

Step 6: Continue Installing Panels

Take the next panel and connect it to the first panel using its interlocking design. Secure it with screws as you did with the first panel. Continue this process until the entire wall is installed. Check the level periodically to ensure the panels remain straight.

Step 7: Finishing Touches

After all panels are installed, you may need to add decorative strips at edges, corners, and openings for a more refined look.
